Used HYUNDAI 305LC Excavator 30ton for sale High-Strength Redundant Structure

1. Core Power & Powertrain (Engine)

The R305LC-9 is equipped with a high-displacement industrial engine, engineered to deliver sustained power and massive torque for heavy-duty material handling and deep excavation tasks.

Parameter	Metric System	Imperial System	Technical Remarks
Engine Model	Cummins QSL9	Cummins QSL9	6-cylinder, Turbocharged, Air-to-Air Intercooler
Net Flywheel Power	172 kW	231 hp	Rated @ 1,900 rpm
Displacement	8.9 L	543 cu in	Massive torque reserve for high-load cycles
Emission Standard	Tier 3 / Stage IIIA	Tier 3 / Stage IIIA	Standard global export configuration

---

2. Weight, Capacities & Logistics Dimensions

The “LC” (Long Carriage) configuration provides an enlarged footprint, ensuring superior platform stability during high-impact loading and rock-breaking operations.

Parameter	Metric System	Imperial System	Shipping & Logistics Relevance
Operating Weight	30,200 kg	66,580 lbs	Reinforced HD structural configuration
Transport Length	10,700 mm	35.10 ft	Standard heavy-haul flatbed compatible
Transport Width	3,200 mm	10.50 ft	Optimized for high-stability footprint
Transport Height	3,300 mm	10.83 ft	Clearance-compliant for major transport routes
Fuel Tank Capacity	500 L	132.1 gal	Engineered for long, high-output mining shifts

---

3. Hydraulic & Digging Performance

Featuring a high-capacity, heavy-duty hydraulic system, the R305LC-9 is designed to move massive volumes of material rapidly, minimizing cycle times in primary excavation.

Parameter	Metric System	Imperial System	Field Performance Indicator
Max System Flow	2 x 260 L/min	2 x 68.7 gal/min	High-volume variable displacement pumps
Operating Pressure	35,000 kPa	5,076 psi	Peak power for rock and dense overburden
Swing Speed	10.2 rpm	10.2 rpm	Efficient swing torque for bulk loading
Bucket Breakout Force	192 kN	43,165 lbf	Superior force for severe digging conditions
Stick Digging Force	148 kN	33,270 lbf	Robust power for deep, heavy trenching

---

4. Undercarriage & Mobility

The R305LC-9 undercarriage is built to survive the extreme environmental stresses of quarrying and mining, providing exceptional traction and ground-bearing reliability.

Parameter	Metric System	Imperial System	Underfoot Mobility
Standard Shoe Width	600 mm	24 in	Triple grouser heavy-duty track pads
Max Travel Speed	5.5 km/h	3.4 mph	Dual-speed auto-shift for transit
Max Traction Force	290 kN	65,200 lbf	Massive climbing power on site inclines
Ground Pressure	62.0 kPa	8.99 psi	Stable footing for high-impact work

---

5. Working Ranges

Defining the operational capacity for large-scale mining, heavy infrastructure foundations, and primary site preparation.

Parameter	Metric System	Imperial System
Max Digging Depth	7,100 mm	23.30 ft
Max Reach (Ground)	10,600 mm	34.78 ft
Max Cutting Height	10,200 mm	33.46 ft
Max Loading Height	7,200 mm	23.62 ft
