Used HYUNDAI HX220HD Excavator 22ton for sale Optimized Hydraulic Response
*Stringent Quality Assurance: This used construction equipment has successfully passed 15 comprehensive inspections, ensuring top-notch performance across the engine, hydraulic systems, and structural components. Every part is in peak condition, ready to handle demanding tasks from the get-go.
*Cost-Effective Solution: Skip the hefty price tag of new machinery. Our used construction equipment can save more than 20% on initial costs while maintaining over 80% of its original operational efficiency, making it the perfect choice for maximizing project budgets.
*Proven Dependability: With verified low operating hours and a complete service history, this machine has consistently excelled in demanding tasks like mining and road construction. Trusted by contractors globally, it’s a reliable workhorse for any project.
1. Core Power & Powertrain (Engine)
The HX220HD is powered by a high-efficiency engine tuned for maximum torque retention under heavy load. It balances high-output performance with reduced fuel consumption through advanced electronic management.
| Parameter | Metric System | Imperial System | Technical Remarks |
| Engine Model | Cummins QSB6.7 | Cummins QSB6.7 | 6-cylinder, Turbocharged, CRDI |
| Net Flywheel Power | 130 kW | 174 hp | Rated @ 1,900 rpm |
| Displacement | 6.7 L | 409 cu in | High torque for aggressive cycles |
| Emission Standard | Tier 3 / Stage IIIA | Tier 3 / Stage IIIA | Global export configuration |
2. Weight, Capacities & Logistics Dimensions
The “HD” designation indicates a reinforced lower structure. These dimensions are critical for logistics planning to ensure secure and efficient mobilization of the unit.
| Parameter | Metric System | Imperial System | Shipping & Logistics Relevance |
| Operating Weight | 23,100 kg | 50,927 lbs | HD (Heavy-duty) configuration |
| Transport Length | 9,600 mm | 31.50 ft | Optimized for flatbed transport |
| Transport Width | 2,990 mm | 9.81 ft | Enhanced stability stance |
| Transport Height | 3,060 mm | 10.04 ft | Standard clearance compliance |
| Fuel Tank Capacity | 400 L | 105.7 gal | Designed for extended site autonomy |
3. Hydraulic & Digging Performance
Hyundai’s IPC (Intelligent Power Control) system in the HX series dynamically optimizes pump flow and engine speed, delivering superior breakout force for high-density materials.
| Parameter | Metric System | Imperial System | Field Performance Indicator |
| Max System Flow | 2 x 222 L/min | 2 x 58.6 gal/min | Variable displacement piston pumps |
| Operating Pressure | 35,000 kPa | 5,076 psi | Maximum power for rock/heavy soil |
| Swing Speed | 11.4 rpm | 11.4 rpm | Fast cycle times for bulk loading |
| Bucket Breakout Force | 165 kN | 37,090 lbf | Extreme force for hard-packed terrain |
| Stick Digging Force | 120 kN | 26,980 lbf | Robust power for heavy utility trenching |
4. Undercarriage & Mobility (HD Configuration)
The HD undercarriage features reinforced track guides and thicker high-tensile steel components to survive the extreme environmental stresses of quarrying and mining.
| Parameter | Metric System | Imperial System | Underfoot Mobility |
| Standard Shoe Width | 600 mm | 24 in | Triple grouser heavy-duty track pads |
| Max Travel Speed | 5.5 km/h | 3.4 mph | Dual-speed auto-shift for transit |
| Max Traction Force | 208 kN | 46,760 lbf | Superior climbing power on inclines |
| Ground Pressure | 50.0 kPa | 7.25 psi | Optimized for load-bearing and stability |
5. Working Ranges
Defining the essential operational envelope for large-scale site preparation and primary material extraction.
| Parameter | Metric System | Imperial System |
| Max Digging Depth | 6,650 mm | 21.82 ft |
| Max Reach (Ground) | 9,930 mm | 32.58 ft |
| Max Cutting Height | 9,750 mm | 31.99 ft |
| Max Loading Height | 6,850 mm | 22.47 ft |
